YF-E Soft And Hard High Speed Grooved Drum Winder

YF-E soft and hard winding machine applies to cotton, wool, mix, fibre and low spring silk. It can wind the yarn as tube or flat soft cone and is used for bobbin dying technics. It can wind soft packages and hard packages before or after dyeing.

This soft package grooved drum winder is one spindle drived by one motor, and this loose and tight bobbin winder is equipped with mechanical yarn clearer..

This cotton yarn winder is double sided, and the min. spindle is 12 spindles, and the max. spindles can be 96 spindles.

The distance between spindles is 330mm. and the spindle speed of the soft cone winding machine is 300—1200m/min. the capacity can be 152 x 290mm.

The grooved drum thread winding machine includes I) Aluminum alloy drums 0. 0', II) Single spindle yarn broke stop motion, III) With 0. 0" cradles, IV) Tension device on each spindle, V) Magnetic Switch, VI) Travel clean blower, VII) Inverted. VIII) Ribon breaker. IX)Overhead blower.
